🔲 4-Bit Comparator with Cascadable Comparator Cells

EEE458 — VLSI II | Group 11
Arindam Dev (1106040) & Md. Shamim Hussain (1106032)
Department of EEE, Bangladesh University of Engineering and Technology (BUET)
Supervised by Dr. A.B.M. Harun-ur Rashid & Tariqul Islam

📌 Overview

A full top-down VLSI design of a 4-bit magnitude comparator using cascadable 1-bit comparator cells, verified through behavioral simulation, gate-level simulation, transistor-level schematic, layout, DRC/LVS checking, and tapeout. The design follows a complementary-cell architecture (COMPA / COMPB) to minimize logic complexity and propagation delay.

🎯 Design Specifications

Parameter Value
Function Compare two 4-bit numbers A and B
Outputs COUT (A > B), DOUT (A < B); both 0 means A = B
Cell architecture Cascadable 1-bit comparator cells (COMPA + COMPB)
Total transistors 96 (4 cells × 24 transistors each)
Technology gpdk090 (90nm CMOS)
Propagation delay 197 ps (TT corner)
Chip size 129.37 µm × 80.9 µm

🧠 Logic Design

Each 1-bit comparator cell takes 4 inputs — Ai, Bi, Ci+1 (greater-from-previous), Di+1 (less-from-previous) — and produces 2 outputs:

Ci  = 1  if  Ai > Bi  (or if already Ci+1 = 1)
Di  = 1  if  Ai < Bi  (or if already Di+1 = 1)
Ci = Di = 0  if  Ai = Bi  and  Ci+1 = Di+1 = 0

Two complementary cell types alternate across stages to reduce gate count:

COMPA (true inputs → inverted outputs):

C̄ᵢ = NOR(Ci+1, Di+1, Āᵢ, Bᵢ)
D̄ᵢ = NOR(Di+1, Ci+1, Aᵢ, B̄ᵢ)

COMPB (inverted inputs → true outputs):

Ci-1 = NAND(C̄ᵢ, D̄ᵢ, Aᵢ₋₁, B̄ᵢ₋₁)
Di-1 = NAND(D̄ᵢ, C̄ᵢ, Āᵢ₋₁, Bᵢ₋₁)

4-bit cascade arrangement:

A3,B3 → [COMPB] → [COMPA] → [COMPB] → [COMPA] → COUT, DOUT
              stage3    stage2    stage1    stage0

⚙️ Design Flow (Top-Down Hierarchy)

1. Behavioral (Verilog HDL)
        │  Quartus II functional simulation ✓
        ▼
2. Gate Level (Orcad + PSpice)
        │  Transient simulation with 74xx gates ✓
        ▼
3. Transistor Level (Cadence Schematic L)
        │  Logical effort sizing, TT/FF/SS/FS corners ✓
        ▼
4. Cell Layout (Cadence Layout XL)
        │  COMPA: 16.345µm × 8.005µm
        │  COMPB: 10.5µm × 8.045µm
        │  DRC: No errors ✓ | LVS: Match ✓
        ▼
5. Parasitic Extraction (Cadence ASSURA)
        │  Post-layout simulation ✓
        ▼
6. Full Chip + I/O Pads → Tapeout (GDS)

💻 Verilog Implementation

// Top-level 4-bit comparator
module comp4(Cin, Din, A, B, Cout, Dout);
    input  Cin, Din;
    output Cout, Dout;
    input  [3:0] A, B;
    wire   [2:0] C, D;

    compb stage3(Cin,  Din,  A[3], B[3], C[2], D[2]);
    compa stage2(C[2], D[2], A[2], B[2], C[1], D[1]);
    compb stage1(C[1], D[1], A[1], B[1], C[0], D[0]);
    compa stage0(C[0], D[0], A[0], B[0], Cout, Dout);
endmodule

// COMPA cell — true inputs, inverted outputs
module compa(Cc, Dc, A, B, C, D);
    input  Cc, Dc, A, B;
    output C, D;
    assign C = ~(Cc & ~(Dc & A & ~B));
    assign D = ~(Dc & ~(Cc & ~A & B));
endmodule

// COMPB cell — inverted inputs, true outputs
module compb(C, D, A, B, Cc, Dc);
    input  C, D, A, B;
    output Cc, Dc;
    assign Cc = ~(C | ~(D | ~A | B));
    assign Dc = ~(D | ~(C | A | ~B));
endmodule

📊 Simulation Results

Timing Performance (Transistor Level, TT corner)

Parameter Value
Rise time — output C 91.73 ps
Fall time — output C 91.73 ps
Rise time — output D 39.2 ps
Fall time — output D 39.2 ps
Propagation delay 197 ps

Process Corner Simulations

Corner Status
TT (Typical-Typical) ✅ Pass
FF (Fast-Fast) ✅ Pass
FS (Fast-Slow) ✅ Pass
SS (Slow-Slow) ✅ Pass

🏗️ Layout Details

Cell Sizes

Cell Width Height Transistors
COMPA 16.345 µm 8.005 µm 24 (12P + 12N)
COMPB 10.5 µm 8.045 µm 24 (12P + 12N)
Full chip 129.37 µm 80.9 µm 96 total

Verification Checks

Check Tool Result
DRC Cadence Assura ✅ No errors
LVS Cadence Assura ✅ Schematic & layout match
Parasitic extraction ASSURA av_extracted ✅ Completed
Tapeout (GDS stream out) Virtuoso ✅ 0 errors, 0 warnings

Floorplan Strategy

  • Inputs Aᵢ and Bᵢ enter from top and bottom of each cell
  • Cᵢ and Dᵢ propagate horizontally between cells
  • VDD/GND rails run horizontally, distributed at right angles within cells
  • Cell height is fixed; chip width scales linearly with bit-width → easily extensible to N-bit comparator

🛠️ Tools Used

Tool Purpose
Quartus II Verilog compilation & functional simulation
Orcad + PSpice Gate-level schematic & transient simulation
Cadence Schematic L Transistor-level schematic entry
Cadence Layout XL Cell and chip layout
Cadence Assura DRC, LVS, parasitic extraction
Cadence Virtuoso Full chip integration & GDS stream out

📄 References

  1. Pucknell, D. A., & Eshraghian, K. Basic VLSI Design, 3rd ed. Prentice Hall, 1994.
  2. Weste, N. H. E., Harris, D., & Banarjee, A. CMOS VLSI Design: A Circuits and Systems Perspective, 3rd ed. Pearson Education, 2008.
  3. Wikipedia — Integrated Circuit Layout
